规格型号

Model

连接管内径d0(mm)
Inner diameter for Connecting pipe

连接螺纹尺寸Size of connecting thread

长度L

length

备注

Remarks

英制G(BS)

公制M(MS)

NGe-III 13×700

13

G1/2"

M20×1.5
M22×1.5

700

(1)挠性管长度可根据现场使用需要定制

The length of the dust-proof flexible hose would be determined according to the site requirements.

(2)螺纹规格可按现场需要定制成公制螺纹或NPT螺纹

The thread specification would be metric or NPT thread according to the site requirements.

NGe-III 20×700

20

G3/4"

M24×1.5
M27×1.5

700

NGe-III 25×700

25

G1"

M32×1.5

700

NGe32-III 32×1000

32

G1 1/4"

M40×1.5

1000

NGe-III 38×1000

38

G1 1/2"

M50×1.5

1000

NGe-III 51×1200

51

G2"

M60×1.5

1200

NGe-III 64×1200

64

G2 1/2"

M75×1.5

1200

NGe-III 75×1400

75

G3"

M90×1.5

1400

NGe-III 100×2000

100

G4"

M110×2.0

2000
