YZG14-1 单头短节•单头加厚短节Single Head Short-circuit • Thick Single Head Short-circuit
YZG14-1 单头短节•单头加厚短节Single Head Short-circuit • Thick Single Head Short-circuit-镇江市天涯电气有限公司
产品编号：
N2012229152025
产品型号：
镇江市天涯电气有限公司
发布日期：
2024-3-18
查看数次：
3477
产 品 详 细 介 绍：
仪表管接头 >> YZG6～16系列自控管路附件 >> YZG14-1 单头短节•单头加厚短节 Instrument pipe joint >> YZG6～16 series automatic control pipeline accessories >> YZG14-1 Single Head Short-circuit • Thick Single Head Short-circuit
Explain: This series collects all kinds of connection forms and structural couplings, nipples, nozzles, rotary couplings, thermowells and other products in the automatic control instrument pipeline system. It is an essential connecting piece in the pipeline with a wide range of varieties, specifications and applications. The short joint YZG14 series is essentially a pressure taking part. It is applicable to various measuring circuits, especially pressure, flow and liquid level.
YZG14-1 单头短节•单头加厚短节 YZG14-1 Single Head Short-circuit • Thick Single Head Short-circuit
ZG
D
d0
L
代号Code No.
ZG1/4"
14
8
50
YZG14-1-ZG1/4"-50
ZG3/8"
18
10
70
YZG14-1-ZG3/8"-70
ZG1/2"
22
15
70
YZG14-1-ZG1/2"-70
ZG3/4"
27
20
70
YZG14-1-ZG3/4"-70
ZG1"
34
27
100
YZG14-1-ZG1"-100
ZG1 1/2"
48
31
100
YZG14-1-ZG1 1/2"-100
ZG2"
60
45
120
YZG14-1-ZG2"-120
ZG1/4"
14
3
50
YZG14-1-ZG1/4"-50-J
ZG3/8"
18
5
70
YZG14-1-ZG3/8"-70-J
ZG1/2"
22
10
70
YZG14-1-ZG1/2"-70-J
ZG3/4"
27
15
70
YZG14-1-ZG3/4"-70-J
ZG1"
34
22
100
YZG14-1-ZG1"-100-J
ZG1 1/2"
48
28
100
YZG14-1-ZG1 1/2"-100-J
ZG2"
60
40
120
YZG14-1-ZG2"-120-J
可指定长度L定制生产 YZG14-1 单头短节•单头加厚短节多用于压力取源部件，一头焊在压力点，一端用螺纹与一次阀连接。代号中注“J”者为加厚短节，用途与规格同单头短节，只是使用在压力等级高的场合。 YZG14-1 single-head short joint • single-head thickened short joint is mostly used for pressure source parts, one end is welded at the pressure point, and one end is connected with the primary valve with thread. Those marked with "J" in the code are thickened nipples. The purpose and specification are the same as single-head nipples. They are only used in occasions with high pressure rating.
※注：YZG14-1 单头短节•单头加厚短节Single Head Short-circuit • Thick Single Head Short-circuit如有改进，恕不另行通知，以产品实物为准。
