公称通径

公称压力

接头螺纹

外形尺寸

配管外径

代  号Code No.

DN

PN(Mpa)

d

L

L1

H1

H2

D0

4

6.4

M10×1

48

19

30

32

6

YZQ-1C-Q81SA-64-M10×1-Φ6 DN4 PN6.4

4

6.4

ZG1/8"

48

19

30

32

6

YZQ-1C-Q81SA-64-ZG1/8"-Φ6 DN4 PN6.4

4

6.4

ZG1/4"

50

21

30

32

6

YZQ-1C-Q81SA-64-ZG1/4"-Φ6 DN4 PN6.4

4

6.4

G1/4"

50

21

30

32

6

YZQ-1C-Q81SA-64-G1/4"-Φ6 DN4 PN6.4

6

6.4

M10×1

52

21

30

42

8

YZQ-1C-Q81SA-64-M10×1-Φ8 DN6 PN6.4

6

6.4

ZG1/8"

52

21

30

42

8

YZQ-1C-Q81SA-64-ZG1/8"-Φ8 DN6 PN6.4

6

6.4

ZG1/4"

54

23

30

42

8

YZQ-1C-Q81SA-64-ZG1/4"-Φ8 DN6 PN6.4

6

6.4

G1/4"

54

23

30

42

8

YZQ-1C-Q81SA-64-G1/4"-Φ8 DN6 PN6.4

8

6.4

M10×1

58

24

38

50

10

YZQ-1C-Q81SA-64-M10×1-Φ10 DN8 PN6.4

8

6.4

ZG1/8"

58

24

38

50

10

YZQ-1C-Q81SA-64-ZG1/8"-Φ10 DN8 PN6.4

8

6.4

ZG1/4"

60

26

38

50

10

YZQ-1C-Q81SA-64-ZG1/4"-Φ10 DN8 PN6.4

8

6.4

G1/4"

60

26

38

50

10

YZQ-1C-Q81SA-64-G1/4"-Φ10 DN8 PN6.4
